NET-UBQ-SW-USW-PRO-24-POE

The Ubiquiti USW-Pro-24-PoE is a high-performance 24-port managed switch with advanced Power over Ethernet (PoE) capabilities, perfect for powering a variety of network devices like access points, IP cameras, and VoIP phones.
Featuring 16 PoE+ ports with a total power budget of 400W, along with 2 10G SFP+ ports for high-speed fibre uplinks, it offers unparalleled flexibility and speed.
Its robust Layer 3 switching features and smart cooling system with near-silent fans make it ideal for both business and enterprise environments.
Easily manage your network with the intuitive UniFi Controller, optimising performance and simplifying setup.
Elevate your infrastructure with the USW-Pro-24-PoE for ultimate power, scalability, and reliability.

Mechanical
Dimensions		442 x 285 x 44 mm
Weight		Without mounting brackets: 4.3 kg With mounting brackets: 4.4 kg
Enclosure material		SGCC steel
Hardware
Management interface		Ethernet In-Band
Networking interface		(24) GbE RJ45 ports (2) 1/10G SFP+ ports
PoE interface		(16) PoE/PoE+ (Pins 1, 2+; 3, 6-) (8) 60W PoE++; PoE/PoE+ (Pins 1, 2+; 3, 6-) / PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput		44 Gbps
Switching capacity		88 Gbps
Forwarding rate		65.472 Mpps
Power method		(1) Universal input, 100—240V AC, 50/60 Hz (1) USP-RPS DC input, 52V DC, 7.69A; 11.5V DC, 2.61A
Power supply		AC/DC, internal, 450W
Supported voltage range		100—240V AC
Max. power consumption		50W (Excluding PoE output)
Total available PoE		400W
Max. PoE wattage per port by PSE		PoE+: 32W PoE++: 64W
Voltage range PoE mode		PoE: 44-57V PoE+: 50-57V
ESD/EMP protection		Air: ± 16kV, contact: ± 12kV
LCM display		(1) 1.3" touchscreen
Button		Factory reset
Shock and vibration		ETSI300-019-1.4 Standard
Ambient operating temperature		-5 to 40° C
Ambient operating humidity		10 to 90% noncondensing
Certifications		CE, FCC, IC
Switching Features
Layer 2 features		IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features		DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs
LEDs
System		Status
Ethernet		PoE Speed/link/activity
SFP+		Link/activity
Application Requirements
UniFi Network		Version 5.10.5 and later
