NET-UBQ-SW-USW-16-POE

The Ubiquiti USW-16-PoE is a compact, high-performance 16-port managed switch with Power over Ethernet (PoE) support, ideal for powering devices such as UniFi access points, IP cameras, and VoIP phones.
Featuring 8 Gigabit PoE ports with a total power budget of 42W, this switch delivers reliable network connectivity and power in a sleek, fanless design for quiet operation.
Easily manage and monitor your network through the intuitive UniFi Controller, making setup and optimisation effortless.
The USW-16-PoE is the perfect choice for small businesses and home networks seeking to expand their infrastructure with ease and efficiency.

Mechanical
Dimensions		442 x 200 x 44 mm
Weight		Without mounting brackets: 2.8 kg With mounting brackets: 2.9 kg
Enclosure material		SGCC steel
Hardware
Management interface		Ethernet In-Band
Networking interface		(16) GbE RJ45 ports (2) 1G SFP ports
PoE interface		(8) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput		18 Gbps
Switching capacity		36 Gbps
Forwarding rate		26.78 Mpps
Power method		Universal input, 100—240V AC, 50/60 Hz
Power supply		AC/DC, internal, 60W
Supported voltage range		100—240V AC
Max. power consumption		18W (Excluding PoE output)
Total available PoE		42W
Max. PoE wattage per port by PSE		PoE+: 32W
Voltage range PoE mode		PoE: 44-57V PoE+: 50-57V
ESD/EMP protection		Air: ± 16kV, contact: ± 12kV
LCM display		(1) 1.3" touchscreen
Button		Factory reset
Shock and vibration		ETSI300-019-1.4 Standard
Ambient operating temperature		-5 to 40° C
Ambient operating humidity		10 to 90% noncondensing
Certifications		CE, FCC, IC
Switching Features
Layer 2 features		IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features		–
LEDs
System		Status
Ethernet		PoE Speed/link/activity
SFP		Link/activity
Application Requirements
UniFi Network		Version 7.2.94 and later
