Ubiquiti UniFi Dream Machine Pro Max Firewall Gateway

  • UDM-Pro-Max
headset

Local Support in Australia and New Zealand

heroicons/outline/truck

Quick Delivery Wide stock availability to respond to most requirements.

Need help from a specialist?

Our specialist support is available!

The Ubiquiti UniFi Dream Machine Pro Max (UDM-Pro-Max) is a high-performance enterprise-grade network device that integrates a cloud gateway, an 8-port Gigabit router, and an NVR (Network Video Recorder) into a single compact unit.
Designed for small to medium businesses, it offers impressive performance with a 2 GHz ARM Cortex-A57 quad-core processor, 8GB DDR4 memory, and 32GB of onboard storage.
It supports up to 5 Gbps IPS throughput, making it ideal for fast, secure network operations.



The UDM-Pro-Max supports both 2.5G and 10G WAN connections, with multiple LAN ports including a 10G SFP+ port, allowing seamless connectivity with other high-speed network devices.
It also features a built-in 128GB SSD for local NVR recordings, which can be expanded with additional drives for more storage capacity.
This device ensures advanced network security with features like a full stateful firewall, VPN support, and content filtering, making it a powerhouse for any business seeking robust, high-speed networking solutions

Mechanical
Dimensions 442.4 x 43.7 x 285.6 mm
Weight 4.7 kg
Enclosure material Aluminium CNC, SGCC steel
Mount material SGCC steel



Hardware
Processor Quad-core ARM® Cortex®-A57 at 2.0 GHz
System memory 8 GB DDR4
On-board storage 32 GB eMMC
Integrated 128 GB SSD
Management interface Ethernet
Bluetooth
Networking interface LAN:
(8) GbE RJ45 ports
(1) 10G SFP+ port

WAN:
(1) 2.5 GbE RJ45 port
(1) 10G SFP+ port
IDS/IPS throughput 5 Gbps*
*Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
Power method (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 8.7A
Power supply AC/DC, internal, 100W
Supported voltage range 100—240V AC
Max. power consumption 100W
ESD/EMP protection Air: ± 15kV, contact: ± 8kV
LCM display (1) 1.3" touchscreen
Button Factory reset
Ambient operating temperature -10 to 40° C
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC



Gateway Features
Performance Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting

Next-generation security Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall

Advanced networking License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support



LEDs
Ethernet Green: link/activity
SFP+ Green: link/activity
HDD White: disk activity
Amber: disk error
RPS Blue: ready
Mpn UDM-Pro-Max
Brand Ubiquiti
